Light-Duty Workbench, KK Type, Mobile, Casters ø75 (Height 810 mm), ø100 (Height: 840 mm)

Name: Light-Duty Workbench, KK Type, Mobile, Casters ø75 (Height 810 mm), ø100 (Height: 840 mm)
Brand: SAKAE
Availability: PreOrder

Brand :

SAKAE

Specification / DimensionsClear all selection

Capacity :

see all
(1) see less

Height (mm) :

see all
(2) see less

Top Plate Material :

see all
(3) see less

Color :

see all
(2) see less

Top Panel Color :

see all
(2) see less

Top Panel Size(mm) :

see all
(2) see less

Days to Ship :

Sort by

Standard Unit Price :

Sort by

Quantity

Standard Unit Price:: ₹ 39,129.33-
Days to Ship :: 10 Day(s) or more

Details

(i)
Caution

The image is an only representative image of the product series. Product specifications vary depending on the part number.
This product will be delivered on the car. Will be shipped to the delivery destination, but will not be unloaded or installed.
This is an assembly type product.
〈Important Notice Regarding List Price〉
After confirming the part number, click the "Confirm Price" button on the right side of the page to see the latest price.

Order Qty :
Starting From :

₹ 39,129.33 /Unit
Total Price :

---
Days to ship :

---

Select part number to Order Now/ Add to Cart

Part Number
KK-58B1I
KK-58B1IG
KK-58B2I
KK-58B2IG
KK-58FB1
KK-58FB1I
KK-58FB2
KK-58FB2I
KK-58SB1
KK-58SB1I
KK-58SB2
KK-58SB2I

Price	Minimum Order Qty.	Days to Ship	Height (mm)	Top Plate Material	Color	Top Panel Color	Top Panel Size (mm)	Caster	JAN code	Mass (kg)	Specifications	Capacity
₹ 39,272.00	1 Piece(s)	10 Day(s) or more	810	Polyester	Ivory	Ivory	1,500 × 600 × 21	ø75 rubber wheels	4549347132327	28	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 39,272.00	1 Piece(s)	10 Day(s) or more	810	Polyester	Sakae green	Ivory	1,500 × 600 × 21	ø75 rubber wheels	4549347132334	28	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 43,433.33	1 Piece(s)	10 Day(s) or more	840	Polyester	Ivory	Ivory	1,500 × 600 × 21	100ø rubber wheels	4549347132365	29	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 43,433.33	1 Piece(s)	10 Day(s) or more	840	Polyester	Sakae green	Ivory	1,500 × 600 × 21	100ø rubber wheels	4549347132372	29	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 44,737.33	1 Piece(s)	10 Day(s) or more	810	Sakae-leum	Sakae green	Green	1,500 × 600 × 21	ø75 rubber wheels	4549347132402	30	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 44,737.33	1 Piece(s)	10 Day(s) or more	810	Sakae-leum	Ivory	Green	1,500 × 600 × 21	ø75 rubber wheels	4549347132419	30	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 49,058.67	1 Piece(s)	10 Day(s) or more	840	Sakae-leum	Sakae green	Green	1,500 × 600 × 21	100ø rubber wheels	4549347132464	32	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 49,058.67	1 Piece(s)	10 Day(s) or more	840	Sakae-leum	Ivory	Green	1,500 × 600 × 21	100ø rubber wheels	4549347132471	32	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 39,129.33	1 Piece(s)	10 Day(s) or more	810	Steel (powder coating)	Sakae green	Green	1,500 × 600 × 25	ø75 rubber wheels	4549347132303	41	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 39,129.33	1 Piece(s)	10 Day(s) or more	810	Steel (powder coating)	Ivory	Ivory	1,500 × 600 × 25	ø75 rubber wheels	4549347132310	41	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 43,665.33	1 Piece(s)	10 Day(s) or more	840	Steel (powder coating)	Sakae green	Green	1,500 × 600 × 25	100ø rubber wheels	4549347132389	42	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 43,665.33	1 Piece(s)	10 Day(s) or more	840	Steel (powder coating)	Ivory	Ivory	1,500 × 600 × 25	100ø rubber wheels	4549347132396	42	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit

Part Number

Part Number	Price	Minimum Order Qty.	Volume Discount	Days to Ship	Height (mm)	Top Plate Material	Color	Top Panel Color	Top Panel Size (mm)	Caster	JAN code	Mass (kg)	Specifications	Capacity

Basic Specifications

Product Type

Lightweight Workbench (Uniform Load of up to 500 kg)
Assembly / Completion

Assembly type
Main body: option

Main Body
Capacity

1 unit

Product Description

A light-duty mobile workbench with casters suitable for standing work.
[Features]
·Because the main body uses a squire pipe (structural steel pipe for structural purposes), it is extremely robust, and moreover, hardly collect dust.
·Uniformly distributed load capacity: 200 kg. Comes standard with metal fittings for stable straight-line motion that stops the rotation of the casters. Selectable according to the site and applications.
·Features straight-line motion when metal fittings are attached. Features turning performance when metal fittings are not attached.
·Optional panel can be attached.
·The caster come with ø75 (diameter 75 mm) and ø100 (diameter 100 mm) rubber wheel. 2 casters come with a brake and 2 casters have no brake.
[Applications]
·By attaching casters, you can easily change the production line, secure a work space, and change the layout.
·This product is suitable for standing work and can improve work efficiency and reduce the burden by selecting a height that suits the user and work.

Part Numbers

Part Number
KK-58B1I
KK-58B1IG
KK-58B2I
KK-58B2IG
KK-58FB1
KK-58FB1I
KK-58FB2
KK-58FB2I
KK-58SB1
KK-58SB1I
KK-58SB2
KK-58SB2I

Price	Minimum Order Qty.	Days to Ship	Height (mm)	Top Plate Material	Color	Top Panel Color	Top Panel Size (mm)	Caster	JAN code	Mass (kg)	Specifications	Capacity
₹ 39,272.00	1 Piece(s)	10 Day(s) or more	810	Polyester	Ivory	Ivory	1,500 × 600 × 21	ø75 rubber wheels	4549347132327	28	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 39,272.00	1 Piece(s)	10 Day(s) or more	810	Polyester	Sakae green	Ivory	1,500 × 600 × 21	ø75 rubber wheels	4549347132334	28	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 43,433.33	1 Piece(s)	10 Day(s) or more	840	Polyester	Ivory	Ivory	1,500 × 600 × 21	100ø rubber wheels	4549347132365	29	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 43,433.33	1 Piece(s)	10 Day(s) or more	840	Polyester	Sakae green	Ivory	1,500 × 600 × 21	100ø rubber wheels	4549347132372	29	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 44,737.33	1 Piece(s)	10 Day(s) or more	810	Sakae-leum	Sakae green	Green	1,500 × 600 × 21	ø75 rubber wheels	4549347132402	30	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 44,737.33	1 Piece(s)	10 Day(s) or more	810	Sakae-leum	Ivory	Green	1,500 × 600 × 21	ø75 rubber wheels	4549347132419	30	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 49,058.67	1 Piece(s)	10 Day(s) or more	840	Sakae-leum	Sakae green	Green	1,500 × 600 × 21	100ø rubber wheels	4549347132464	32	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 49,058.67	1 Piece(s)	10 Day(s) or more	840	Sakae-leum	Ivory	Green	1,500 × 600 × 21	100ø rubber wheels	4549347132471	32	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 39,129.33	1 Piece(s)	10 Day(s) or more	810	Steel (powder coating)	Sakae green	Green	1,500 × 600 × 25	ø75 rubber wheels	4549347132303	41	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 39,129.33	1 Piece(s)	10 Day(s) or more	810	Steel (powder coating)	Ivory	Ivory	1,500 × 600 × 25	ø75 rubber wheels	4549347132310	41	Load capacity per caster: 60 kg / estimated time for assembly: 20 minutes	1 unit
₹ 43,665.33	1 Piece(s)	10 Day(s) or more	840	Steel (powder coating)	Sakae green	Green	1,500 × 600 × 25	100ø rubber wheels	4549347132389	42	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit
₹ 43,665.33	1 Piece(s)	10 Day(s) or more	840	Steel (powder coating)	Ivory	Ivory	1,500 × 600 × 25	100ø rubber wheels	4549347132396	42	Load capacity per caster: 50 kg / estimated time for assembly: 20 minutes	1 unit

Part Number

Part Number	Price	Minimum Order Qty.	Volume Discount	Days to Ship	Height (mm)	Top Plate Material	Color	Top Panel Color	Top Panel Size (mm)	Caster	JAN code	Mass (kg)	Specifications	Capacity

The specifications and dimensions of some parts may not be fully covered. For exact details, refer tomanufacturer catalogs.

Product Specifications

Product features and specifications

External view

External appearance of Light-Duty Workbench, KK Type. With 2 metal fittings for stable straight-line motion

Basic specifications and features of the product

Various sizes are available from W 900 to 1,800 mm × D 600 to 900 mm × H840 mm.
Uniformly distributed load capacity: 200 kg. The indicated uniformly distributed load capacity is based on a safety factor of 20%. The main body is structured with square pipes (structural steel pipes), making it very robust.

Metal fittings for stable straight-line motion

·The mobile workbench comes standard with metal fittings to stop the rotation of the casters. ·It can be installed and selected according to the site and application.

The mobile workbench comes standard with metal fittings to stop the rotation of the casters.
It can be installed and selected according to the site and application.
