Round Posts One End Threaded, One End Tapped, Length Selectable/Configurable

Brand :

MISUMI

Caution

Product Description

New at MISUMI? Get 20% Discount on your First Purchase. Click to Register Now

Product Overview

Round post is a common processing component, with the functions of connection, fastening, support, separation and so on, mainly used in various fastening and supporting mechanisms.
At the same time, there are a variety of materials to choose from, allowing it to be widely used in automation, electronics and electrical appliances, medical treatment, communication and other fields.

Dimensional Drawing

MISUMI Round Posts Imported From Japan, One End Threaded, Japanese Quality

Material Specifications

Type					Material	Surface Treatment	B (mm)	L (mm)
L dimension fixed type	L dimension configurable
L dimension fixed type	Standard	With Wrench Slot Type	Designated thread type	Thread-Specified Type · With Wrench Slot Type
-	E-NETGRF	E-NETGRS	E-NETG	E-NETGS	General Structural Steel or Carbon Steel	-	5 to 50	15 to 1000
E-ETKGR	E-ETKGRF	E-ETKGRS	E-ETKG	E-ETKGS		Black Oxide
E-PETGR	E-PETGRF	E-PETGRS	E-PETG	E-PETGS		Electroless Nickel Plating
E-SETGR	E-SETGRF	E-SETGRS	E-SETG	E-SETGS	Stainless Steel	-

If there are requirements for rust prevention, give priority to products made of stainless steel or those with surface treatment of electroless nickel plating. For rust prevention methods, please click

Rust Prevention Methods.

Products made of general structural steel or carbon steel are coated with anti-rust oil.

The female thread may not be surface treated.

Due to female thread processing, the D part of the female thread may sometimes be slightly raised.

There may be grinding gloss marks near the wrench slot on products without surface treatment.

SC≤L－L1

Specification Table

■ L dimension fixed type

Part Number		L																			M (Coarse Thread)	S	W	ℓ₁
Type	D	L																			M (Coarse Thread)	S	W	ℓ₁
General Structural Steel or Carbon Steel E-ETKGR E-PETGR Stainless Steel E-SETGR	6	15	20	25	30	35	40	45	50												3	3.5	5	8
	8		20	25	30	35	40	45	50	60	70	80	90	100	110	120	130	140	150		4	6	7
	10		20	25	30	35	40	45	50	60	70	80	90	100	110	120	130	140	150	200	5	6	8
	12			25	30	35	40	45	50	60	70	80	90	100	110	120	130	140	150	200	6	7.5	10	10
	15				30	35	40	45	50	60	70	80	90	100	110	120	130	140	150	200	8	10	13
	20						40	45	50	60	70	80	90	100	110	120	130	140	150	200	10	15	17

■ L Size Specification Type / L Size Specification・With Wrench Slot Type

Part Number			L 0.5mm increments	SC 1mm increments Only for models with wrench slot	M (Coarse Thread)	W	ℓ₁
Type		D	L 0.5mm increments	SC 1mm increments Only for models with wrench slot	M (Coarse Thread)	W	ℓ₁
L Size Specified Type General Structural Steel or Carbon Steel E-NETGRF E-ETKGRF E-PETGRF Stainless Steel E-SETGRF	L Size Specified Type・With Wrench Slot General Structural Steel or Carbon Steel E-NETGRS E-ETKGRS E-PETGRS Stainless Steel E-SETGRS	5	15～ 100	0～ 92	2.6	4	8
		6	15～ 100	0～ 42	3	5
		8	20～ 200	0~142	4	7
		10	20～ 400	0~342	5	8
		12	25～ 500	0~390	6	10	10
		15	30～ 600	0~390	8	13
		20	35～ 600	0~390	10	17
		25	45～ 700	0~390	12	22
		30	55～ 800	0~385	16	27	15
		35	55～ 900	0~885	16	30	15
		40	65~1000	0~980	20	36	20
		50	80~1000	0~980	24	41	20

■ Thread Configurable / Thread Configurable, With Wrench Flats

Part Number			L 0.5mm increments	SC 1mm increments Wrench Slot Type Only	M (Coarse) Male Thread Thread Selection											N (Coarse) Female Thread Selection											W	ℓ₁
Type		D	L 0.5mm increments	SC 1mm increments Wrench Slot Type Only	M (Coarse) Male Thread Thread Selection											N (Coarse) Female Thread Selection											W	ℓ₁
Thread Specification General Structural Steel or Carbon Steel E-NETG E-ETKG E-PETG Stainless Steel E-SETG	Thread Specification Wrench Slot Type General Structural Steel or Carbon Steel E-NETGS E-ETKGS E-PETGS Stainless Steel E-SETGS	5	15～ 100	0～ 92	2.6	3	4									2.6	3										4	8
		6	15～ 100	0～ 92		3	4	5									3	4									5
		8	20～ 200	0~192		3	4	5	6								3	4	5								7
		10	20～ 400	0~392		3	4	5	6	8							3	4	5	6							8
		12	25～ 500	0~490			4	5	6	8								4	5	6	8						10	10
		15	30～ 600	0~590				5	6	8	10	12							5	6	8	10					13
		20	40～ 600	0~590				5	6	8	10	12	16						5	6	8	10	12				17
		25	55～ 700	0~690				5	6	8	10	12	16	20					5	6	8	10	12	16			22
		30	65～ 800	0~785				5	6	8	10	12	16	20	24				5	6	8	10	12	16	20		27	15
		35	80～ 900	0~885					6	8	10	12	16	20	24					6	8	10	12	16	20	24	30	15
		40	80~1000	0~980						8	10	12	16	20	24						8	10	12	16	20	24	36	20
		50	80~1000	0~980							10	12	16	20	24							10	12	16	20	24	41	20

When L-SC≤N×3, W-N≥2 is required.

L≥N×3+2

*D ≥ 35 applies only to E-N□□□□, E-E□□□□, and E-P□□□□.
L Dimension tolerances are as follows:
L 15 to 300 ±0.2
L 300.5 to 600 ±0.3
L 600.5 to 1000 ±0.4

Product Features

Feature 1: the length and thread of the round post can be freely specified to accommodate different operating environments.
Feature 2: a variety of materials to choose from: general structural steel, stainless steel, aluminum, brass, resin, etc.
Feature 3: a wide range of surface treatments are available to meet the requirements of various industries: ferroferric oxide protective film (blackening treatment), electroless nickel plating, etc.
Feature 4: Products with surface treatment (electroless nickel plating) and material (stainless steel) for good anti-rust performance are widely used in precision equipment and dust-free environment.
Feature 5: with the main functions of connection, fastening, support and separation, it is often used in mechanisms with various frames as a connection and support component.

Usage Method

Intended Use	Support and Fixation	Fastening and Connection	Separation
Usage Method Diagram
Feature	- Can withstand large loads in the vertical direction - Minimum length tolerance specification selectable to ±0.05 mm, ensuring the stability of the mechanism	- Simple and aesthetic connection	- Connected to the baffle to effectively block the mechanism in operation and prevent interference - Easy to fasten and install in narrow spaces

Precautions

①Fastening method of post
The post is generally fastened by torque method. For bolts, fasten them within the range of fastening torque, otherwise excessive torque will cause thread fracture.
②Anti-rust specification selection and maintenance.
If there are requirements for anti-corrosion performance, select products with surface treatment of electroless nickel plating or those made of stainless steel (stainless steel) when choosing general structural steel products.
General structural steel posts without surface treatment are recommended to be stored in a constant-temperature and dry environment, and regularly applied with anti-rust oil for maintenance.

Example of Use

Factory Direct Selling MISUMI Round Posts Tapped and Threaded Type

Equipment name: Pull-in conveyor
Function description:
The pull-in conveyor is a space-saving type non-driving conveyor
Function: With the collaboration of the pull-in mechanism and the roller bar, the conveying function can be achieved without driving equipment, and the detection is performed with a proximity sensor, thus improving the operation efficiency of the equipment, suitable for narrow spaces with no room at the bottom and difficult for hands to reach in.
Function of round post in the mechanism
①Round post is used as a fastening connector in the mechanism to support the weight of all workpieces on the upper part and increase the stability of the mechanism.
②Because the mechanism is often used in narrow space, the fastening method of round post is very simple and convenient, thus facilitating the installation and maintenance of equipment.
For details, click and refer to

Pull-in Conveyor

Application Industries

Medical	Semiconductor	Electronic & Electrical

Smart Phones	Food	Automotive
