Proximity Sensors Flat Body

Brand :

MISUMI

Caution

Please note that this product is not covered by the RoHS warranty.
This product is not covered by any investigation or warranty regarding overseas laws and regulations such as RoHS, REACH, and TSCA.
No bracket is included. If fixing in two places is required, please select C-Q18N

Product Description

MISUMI supplies high-quality Flat Body Proximity Sensors in India, designed for precise and reliable detection without physical contact. Proximity Sensors with a flat body are compact, space-saving devices used to detect the presence or absence of objects within a specific range. This Flat Body Proximity Sensors are built for long-lasting performance, offering efficient, non-contact operation in tight spaces and challenging environments.

[Feature]
● Shape : Flat body
● Detection Direction : Top Type
● Detection Head Size Dimension : 10 and 18
● Detection Distance (mm.): 3 and 5
● Output Method: NPN(Can select between NO(Normally Open) and NC(Normally Closed)
● Wire Length (m.): 2
[Application]
It is an important component in the automation system, its primary function is to detect objects without requiring any physical contact. These sensors are ideal for applications in automation, manufacturing, and industrial equipment where accuracy and durability are essential. Common uses include detecting objects on conveyor belts, positioning parts in assembly lines, and ensuring safety in automated systems.

Economy Proximity Sensors Flat Body

Flat Body DesignHigh Switching FrequencyTemperature Resilience

- Slim and flat body. Available in multiple dimensions.

- Multiple detection distance options available.

- Available in multiple configurations and output modes.

- Fast switching frequency. Up to 500Hz for certain models. Ideal for high-speed applications, ensuring quick and accurate responses.

- Operates in a wide temperature range -25‹C to +70‹C. Suitable for various environments, including those with extreme temperatures.

MISUMI Standard

Cheaper Price

Product Variety

3D CAD
3D CAD Support

Product Overview

A proximity switch is a type of position switch that operates without mechanical direct contact with moving parts. When an object approaches the sensing surface of the switch within the operating distance, the switch can be activated without mechanical contact or applying any pressure, thereby driving DC electrical devices or providing control commands to computer (PLC) systems. A proximity switch is a type of switch sensor (i.e., a contactless switch). It has the characteristics of both limit switches and micro switches, as well as sensing capabilities. It operates reliably, has stable performance, fast frequency response, long service life, strong anti-interference ability, and features such as waterproofing, shock resistance, and corrosion resistance.

Product Overview

Product Comparison

Model		MISUMI Standard Product	Economy Series
		EMX4−T12	C-Q10	C-Q18
Detection Distance		4mm	3mm	5mm
Output Format		NPN N.O. (Normally Open)	NPN N.O. (Normally Open)/NPN N.C. (Normally Closed)
Dimensions	Sensor Size	27mm x 12mm x 6.5mm	27mm x 10mm x 6mm	30mm x 18mm x 10mm
	Mounting Holes	φ3.2	φ3.2	2 slots (5 x 3.4)
Power Supply		DC 3-wire	DC 3-wire
Rated Operating Voltage		12/24VDC (10 to 30VDC) Allowable ripple rate 3% p-p or below	12/24VDC (10 to 30VDC) Allowable ripple rate 10% p-p or below
Voltage Drop		1V or less	2.5V or less
Switch Hysteresis		Approx. 20% or less	15% or less
Operating Ambient Temperature		-10 to +50 °C	-25 to +70 °C
Temperature Characteristics		Within ±20% (for operation distance at +23°C)	Within ±10% (for operation at +25°C)
Protection Rating		IP67	IP67
Case Material		Polycarbonate	ABS

[ ! ] For other detailed specifications, see the standards table below.

Dimensional Drawing

Detection distance 3 mm
C-Q10-N11(NPN Normally Open)
C-Q10-N12(NPN Normally Closed)
E-Q10-P11(PNP Normally Open)
Dimension 1

Detection distance 4 mm
E-MSMW23N (NPN Normally Open)
E-MSMW23P (PNP Normally Open)

Dimension 2

Detection distance 5 mm
C-Q18-N01(NPN Normally Open)
C-Q18-N02(NPN Normally Closed)
E-Q18-P01(PNP Normally Open)
Dimension 2

Specification Table

Part Number

Output Type

Operating
Mode

Detection Distance L1

Output Method

Operating Voltage

Protection
Rating

Operating Temperature

Short-circuit
Protection

Overload
Current

Sensing Surface
Material

Wire Length

C-Q10-N11

DC 3-wire (NPN)

Top Surface Detection Type

3 mm

Unshielded

10 to 30 V DC

IP67

-25°C to +70°C

YES

100 mA

ABS

2 m

C-Q10-N12

C-Q18-N01

5 mm

Shield

200 mA

C-Q18-N02

E-MSMW23N

4 mm

Unshielded

100 mA

E-MSMW23P

DC 3-wire (PNP)

E-Q10-P11

3 mm

E-Q18-P01

5 mm

Shield

200 mA

Part Number

C-Q10-N11(NPN)

C-Q10-N12(NPN)

C-Q18-N01(NPN)

C-Q18-N02(NPN)

E-MSMW23N (NPN)

E-Q10-P11(PNP)

E-Q18-P01 (PNP)

E-MSMW23P (PNP)

Sensing Distance

3 mm

5 mm

4 mm

Operating Voltage

10 to 30 V DC

Permissible Pulse Voltage

< 10%

No-Load Current

< 10 mA

Overload Current

100 mA

200 mA

100 mA

Leakage Current

< 0.01 mA

Voltage Drop

< 1.5 V

< 2.5 V

< 1.5 V

Switching Frequency

250HZ

500HZ

Response Time

0.5 ms

Switch Hysteresis

< 15%(Sr)

Repeatability

< 1.0%(Sr)

Protection Rating

IP67

Operating Temperature

-25°C to +70°C

Temperature Drift

< 10%(Sr)

Short Circuit Protection

YES

Sensing Surface Material

ABS

Wire Length

2 m

Product Features

Excellent Type 1: High detection accuracy (densely wound coils, stable detection distance)
Excellent Type 2: Both M8/M12 cable specifications use oil-resistant cables (test results far exceed national standards)
Excellent Type 3: Both M8/M12 cable specifications use bend-resistant cables (test results far exceed market products)

Product Feature

DC 3-wire NPN Output
Product Feature

Z_D: Surge Absorption Zener Diode
T_r: NPN Output Transistor
D: Reverse Power Supply Protection Diode

Wiring Diagram
Product Feature

Standard testing equipment, quality guaranteed

Example of Use

Sensor Attenuation Coefficient
Precautions
