Sheet Transfer Dancer Roll

Specifications and Features

Purpose/Function

Supply/Discharge Ejection/Accumulation Drive/Actuation

Tension control of sheet rolls
Controls tension via a dancer mechanism in the sheet feed section and maintains constant tension after adjustment.
The dancer stops if the feed and rewind speeds are the same.
Environment/Operability: Used in sheet-type work supply section; sheet rolls are changed manually.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Low Head Hex Socket Bolt	E-GCBSST3-8	Screw nominal (M): 3 Length L(mm): 8 Material: Stainless steel RoHS10 compliant	4	₹ 3/Piece
②	Deep Groove Ball Bearing	C-SE694ZZ	Precision (JIS): Grade 0 Shield material/shape: Double-sealed type Inner/outer ring material: Stainless steel Basic dynamic load rating (N): 360 Allowable rotational speed (RPM): 8000	10	₹ 71/Piece
③	Linear Bushing - Straight	C-LMUW5	Inner circle diameter dr(φ): 5 Total length L(mm): 28 Outer tube material: Iron Outer tube surface treatment: None	2	₹ 287/Piece
